Prometure PMT-0001 Bluetooth Espresso Pressure Gauge

Specification

·1.4-inch circular TFT screen, with a resolution of 360*360.

·Power supply: Type-C or 16340 lithium battery (the battery needs to be prepared by yourself,16340 specification, without TYPE-C charging port, not CR123A Type). When TYPE-C is on power supply, the 16340 lithium battery inside the body can be charged (when the pressure gauge switch is turned on).

·Shell material: Nylon

·Sensor operating temperature range: -20 to 100 degrees Celsius (For temperatures above 100 degrees, please add an appropriate extension interface before the threaded interface).

·The main body material of the sensor is 304 stainless steel.

·Installation thread: G1/8 (For other installation threads such as G1/4, G1/8, etc., please convert them by yourself.).

·Maximum range: 16Bar (The range can be customized according to customer requirements.

·Measurable medium: water.

·It can be used in conjunction with the ProMeter App.

·Bluetooth mode: Ble 5.0 (Low power)

·Battery life: 3400mAH > 3 hours. The battery capacity is the value marked on the battery packaging, not the actual capacity. The result is measured under low brightness and without Bluetooth connection, for reference only. The specific battery life is affected by the actual battery capacity, product-related Settings and the actual usage environment.

·External dimension：

         Length: 65-70mm(depending on the interface size), width: 46mm, height: 38mm.

        *The appearance dimensions may change due to subsequent component dimensions. Please confirm with customer service for specific details.
